ZKTeco Multibiometric Device SenseFace 3A

SenseFace 3 Series adopts the latest intelligent engineering facial authentication and in-glass fingerprint technology. It supports fingerprint, facial, card authentication with large capacity and speedy authentication, adopts ultimate anti-spoofing algorithm for facial authentication against almost all types of fake photos and videos attack, which offering secure biometric authentication.

Specifications:
Display	2.8" @ TFT Color Touch LED Screen (240*320)
Camera	WDR Binocular Camera @ 1MP
Operation System	Linux
Hardware	CPU: Dual Core@1GHz RAM: 512MB; ROM: 8GB Speaker: 8ohm @1W Microphone: *1 (Sensitivity: -42 dB/ Omni-directional/ Signal-to-Noise Ratio: 58 dB/ Impedance: 2.2kΩ) Supplement Light: No Fingerprint Sensor: In-Glass Fingerprint (Z-ID) (SenseFace 3A)
Authentication Method	Fingerprint / Face / Card / Password (Virtual Keypad)
Fingerprint Template Capacity	6,000 (1: N) (Standard)
Face Template Capacity	3,000 (1: N) (Standard)
Card Capacity	6,000 (1: N) (Standard)
User Capacity	6,000 (1: N) (Standard)
Transaction Capacity	150,000 (1: N)
Max. User Password Length	8 Digits
Biometric Verification Speed	less than 0.5 sec (Fingerprint); less than 0.35 sec (Facial Authentication)
Touchless Biometric Recognition Distance	30cm to 200cm (Facial Authentication)
False Acceptance Rate (FAR) %	FAR ≤ 0.01% (Visible Light Facial Authentication); FAR ≤ 0.0001% (Fingerprint)
False Rejection Rate (FRR) %	FRR ≤ 0.02% (Visible Light Facial Authentication); FRR ≤ 0.01% (Fingerprint)
Biometric Algorithm	ZKFace V4.0; ZKFingerprint V13.0 (Standard) / V10.0 (Optional)
Card Type	ID Card@125 kHz (Standard) IC [email protected] MHz (Optional)
Communication	TCP / IP1 Wi-Fi (IEEE802.11b/g/n/ax) @ 2.4 GHz (Optional) Wiegand (Input or Output) 1 RS485: ZKTeco RS4851 USB: Type A (USB Drive Only) 1 Aux Inputs 1, Electric Lock1, Door Sensor1, Exit Button1, 12V Output*1
Standard Functions	ADMS, DST, Photo Capture, Event Photo Capture, up to 14-digit User ID, Access Levels, Groups, Holidays, Anti-Passback, Record Query, Schedule Bell, Tamper Switch Alarm, Automatic Status Switch, Multiple AuthenticationMethods, SIP Client (Version 2.0), ONVIF (Compatible with Profile S, Profile T, Profile G, Profile C, Profile Q & Profile A), AC Push and TA Push Protocol Switch Switch, HTTPs / SSH Backend Access, T9 Keyboard (Input)
Access Control Interface	RS485 (RS485 Card Reader / Biometric Reader)
Power Supply	DC 12V 3A
Video Intercom	Video Intercom (ZKTeco Private Protocol via TCP/lP) Support Devices: Standalone Terminal: SenseFace Series. Indoor Monitor: VT07-B01, VT07-B01-W Video Intercom (Standard SIP Protocol) Support Devices: Standalone Terminal: SenseFace series. Indoor Monitor: VT07-B22L, VT07-B26L-W. Software: ZKBio CVAccess, BioTalk Pro. Mobile App: ZKBio Zlink, ZKBio Zexus
Optional Functions	IC Card, Wi-Fi, Wireless Doorbell
Operating Temperature	-5°C to 45°C
Operating Humidity	10% to 90% RH (Non-condensing)
Dimensions	166 mm63 mm25 mm (LWH)
Net Weight	0.185 Kg
Installation	Wall-mount (Compatible with Asian Gang Box / Single Gang Box)

Specifications:

Display

2.8" @ TFT Color Touch LED Screen (240*320)

Camera

WDR Binocular Camera @ 1MP

Operation System

Linux

Hardware

CPU: Dual Core@1GHz
RAM: 512MB; ROM: 8GB
Speaker: 8ohm @1W
Microphone: *1 (Sensitivity: -42 dB/ Omni-directional/ Signal-to-Noise Ratio: 58 dB/ Impedance: 2.2kΩ)
Supplement Light: No
Fingerprint Sensor: In-Glass Fingerprint (Z-ID) (SenseFace 3A)

Authentication Method

Fingerprint / Face / Card / Password (Virtual Keypad)

Fingerprint Template Capacity

6,000 (1: N) (Standard)

Face Template Capacity

3,000 (1: N) (Standard)

Card Capacity

6,000 (1: N) (Standard)

User Capacity

6,000 (1: N) (Standard)

Transaction Capacity

150,000 (1: N)

Max. User Password Length

8 Digits

Biometric Verification Speed

less than 0.5 sec (Fingerprint); less than 0.35 sec (Facial Authentication)

Touchless Biometric Recognition Distance

30cm to 200cm (Facial Authentication)

False Acceptance Rate (FAR) %

FAR ≤ 0.01% (Visible Light Facial Authentication); FAR ≤ 0.0001% (Fingerprint)

False Rejection Rate (FRR) %

FRR ≤ 0.02% (Visible Light Facial Authentication); FRR ≤ 0.01% (Fingerprint)

Biometric Algorithm

ZKFace V4.0; ZKFingerprint V13.0 (Standard) / V10.0 (Optional)

Card Type

ID Card@125 kHz (Standard)
IC [email protected] MHz (Optional)

Communication

TCP / IP*1
Wi-Fi (IEEE802.11b/g/n/ax) @ 2.4 GHz (Optional)
Wiegand (Input or Output) *1
RS485: ZKTeco RS485*1
USB: Type A (USB Drive Only) *1
Aux Inputs 1, Electric Lock1, Door Sensor*1, Exit Button*1, 12V Output*1

Standard Functions

ADMS, DST, Photo Capture, Event Photo Capture, up to 14-digit User ID, Access Levels,
Groups, Holidays, Anti-Passback, Record Query, Schedule Bell, Tamper Switch Alarm,
Automatic Status Switch, Multiple AuthenticationMethods, SIP Client (Version 2.0), ONVIF
(Compatible with Profile S, Profile T, Profile G, Profile C, Profile Q & Profile A), AC Push and TA Push Protocol Switch Switch, HTTPs / SSH Backend Access, T9 Keyboard (Input)

Access Control Interface

RS485 (RS485 Card Reader / Biometric Reader)

Power Supply

DC 12V 3A

Video Intercom

Video Intercom (ZKTeco Private Protocol via TCP/lP)
Support Devices:
Standalone Terminal: SenseFace Series.
Indoor Monitor: VT07-B01, VT07-B01-W

Video Intercom (Standard SIP Protocol)
Support Devices:
Standalone Terminal: SenseFace series.
Indoor Monitor: VT07-B22L, VT07-B26L-W.
Software: ZKBio CVAccess, BioTalk Pro.
Mobile App: ZKBio Zlink, ZKBio Zexus

Optional Functions

IC Card, Wi-Fi, Wireless Doorbell

Operating Temperature

-5°C to 45°C

Operating Humidity

10% to 90% RH (Non-condensing)

Dimensions

166 mm*63 mm*25 mm (L*W*H)

Net Weight

0.185 Kg

Installation

Wall-mount (Compatible with Asian Gang Box / Single Gang Box)
