Zebra DS9908
The Zebra DS9908 is a premium hybrid scanner offering handheld and hands-free scanning with high-performance 1D/2D barcode reading and optional RFID functionality, ideal for retail, healthcare, and manufacturing environments.
The Zebra DS9908 is a premium hybrid scanner offering handheld and hands-free scanning with high-performance 1D/2D barcode reading and optional RFID functionality, ideal for retail, healthcare, and manufacturing environments.
Specifications: | ||
|---|---|---|
Physical Characteristics | Dimensions | 8.0 in. H x 3.7 in. W x 5.2 in. D |
Weight | 11.6 oz./330.0 g | |
Input Voltage Range | 4.5 to 5.5 VDC host powered; 4.5 to 5.5 VDC external power supply | |
Operating Current at Nominal Voltage (5.0V) | 321mA (typical) | |
Standby Current (idle) at Nominal Voltage (5.0V) | 70 mA (typical) | |
Supported Host Interfaces | USB, RS232, Keyboard Wedge, TGCS (IBM) 46XX over RS485 | |
Keyboard Support | Supports over 90 international keyboards | |
User Indicators | Direct decode indicator, good decode LEDs, Speaker (adjustable tone and volume) | |
Performance Characteristics | Light Source | Aiming Pattern: Circular 617nm Amber LED |
Swipe Speed (Hands-Free) | Up to 240 in. /610 cm per second for 13 mil UPC in optimized mode | |
Illumination | (2) 645nm Red LEDs | |
Imager Field of View | 48° H x 30.6° V Nominal | |
Image Sensor | 1280*800 pixels | |
Minimum Print Contrast | 16% minimum reflective difference | |
Skew Tolerance | ± 60° | |
Pitch Tolerance | ± 60° | |
Roll Tolerance | 0° - 360° | |
User Environment | Operating Temperature | 32° to 122° F/0° to 50° C |
Storage Temperature | -40° to 158° F/-40° to 70° C | |
Humidity | 5% - 95% RH, non-condensing | |
Drop Specification | Designed to withstand multiple drops at 5.0 ft./1.5 m to concrete | |
Tumble Specification | Designed to withstand 2000 tumbles in 1.5 ft./0.5 m tumbler3 | |
Environmental Sealing | IP52 | |
Electrostatic Discharge (ESD) | ESD per EN61000-4-2, +/-15 KV Air, +/-8 KV Direct, +/-8 KV Indirect | |
Ambient Light Immunity | 0 to 10,000 Foot Candles / 0 to 107,600 Lux | |
Symbol Decode Capacity | 1D | Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32 (Italian Pharma) |
2D | PDF417, Micro PDF417, Composite Codes, TLC-39, Aztec, DataMatrix, MaxiCode, QR Code, Micro QR, Han Xin, Postal Codes | |
OCR | OCR-A, OCR-B, MICR, US Currency | |
Digimarc | Digimarc barcodes | |
Minimum Element Resolution | Code 39 - 3.0 mil | |
