The TC27 is a durable, 5G-enabled device designed for fieldwork. Couriers can capture high-resolution photos for delivery proof and handle on-site payments. Repair technicians can scan parts, make 5G video calls for remote support, and process payments upon service completion. With digital wallet compatibility, the TC27 is versatile for various settings like stadiums, parks, and transit, making it ideal for access control and mobile payments.
Specifications: | ||
|---|---|---|
Physical Characteristics | Dimensions | 6.5 in. L x 3.0 in. W x 0.49 in. D |
Weight | 8.32 oz/236 g (TC22 3800mAh battery) | |
Display | 6.0 in. color Full High Definition+ (1080 x 2160); LED backlight; 450 Nits; Corning™ Gorilla™ Glass | |
Imager Window | Corning Gorilla Glass | |
Touch panel | Multi-mode capacitive touch with bare or light gloved fingertip input | |
Power | User removable, rechargeable Li-Ion, Power Precision for real-time battery metrics; Standard Capacity: 3800 mAh/14.63Wh; Extended Capacity: 5200 mAh/20.02Wh; BLE battery: 3800 mAh/14.63Wh | |
Expansion Slot | User accessible MicroSD with 32 GB SDHC and up to 256 GB SDXC | |
SIM | 1 Nano SIM and 1 eSIM (except China) | |
Network Connections | WWAN, WLAN, WPAN | |
Notification | Audible tone; multi-color LEDs; vibration | |
Keypad | On-screen keypad | |
Audio | Two microphones with noise cancellation; dual speakers for loudness; Bluetooth wireless headset support; high quality speaker phone; PTT headset (Zebra USB-C) support; HD Voice, including Super-wideband (SWB), Wideband (WB) and Full band (FB) | |
Buttons | Dual dedicated scan buttons; programmable button for PTT or other use; volume up/down; power | |
Interface Ports | USB 3.1 (Bottom Type C) —Super Speed (host and client); 2-pin or 8-pin rear connector | |
Performance Characteristics | CPU | Qualcomm™ 5430 hex-core, 2.1 GHz |
Operating System | Android; for supported Android versions | |
Memory | 6 GB RAM/64 GB UFS Flash. | |
User Environment | Operating Temp. | 14°F to 122°F/-10°C to 50°C |
Storage Temp. | -40°F to 158°F/-40°C to 70°C | |
Humidity | 5% to 95% non-condensing | |
Drop Specifications | Multiple 5 ft./1.5 m drops to concrete over operating temp (-10° C to 50° C/14° F to 122° F) with protective boot per MIL-STD-810H | |
Tumble Specifications | 500 tumbles, 1.6 ft./0.5 m; 500 tumbles, 3.3 ft./1.0 m with optional protective boot | |
Sealing | IP68 and IP65, with battery per applicable IEC sealing specifications | |
Electrostatic Discharge (ESD) | +/-15kVdc air discharge; +/-8kVdc direct discharge; +/-8kVdc indirect discharge | |
Interactive Sensor Technology (IST) | Light Sensor | Automatically adjusts display backlight brightness |
Motion Sensor | 3-axis accelerometer with MEMS Gyro | |
Proximity Sensor | Automatically detects when the user places the handset against head during a phone call to disable display output and touch input. | |
Magnetometer | eCompass to detect direction | |
Pressure Sensor | Altitude for locating (TC27 North America only) | |
Data Capture | Scanning | SE55 1D/2D Advanced Range Scan Engine with IntelliFocus™ technology; SE4710 1D/2D Scan Engine |
Camera | Rear camera 16 MP; front camera 5 MP | |
NFC | NFC ISO 14443 Type A and B; Mifare, FeliCa and ISO 15693 cards, NFC Forum tags 2,3,4,5; Host Card Emulation, Contactless Payment Support, VAS (Value Added Services) and Wallet support, Apple ECP1.0 and ECP2.0, Apple VAS and Google Smart Tap certified, VAS Library/SDK | |
UHF RFID | RFD40 UHF RFID Sled; RFD90 Ultra-Rugged UHF RFID Sled | |
Wireless WAN Data and Voice Communications | Radio Frequency Band | North America: 5G FR1: n2/5/7/12/13/14/25/26/29/38/41/48/66/71/77/78; |
GPS | GPS, GLONASS, Galileo, Beidou, QZSS, Dual-Band GNSS — concurrent L1/G1/E1/B1 (GPS/QZSS, GLO, GAL, BeiDou) + L5/E5a/BDSB2a (GPS/QZSS, GAL, BeiDou); a-GPS; supports XTRA | |
Wireless LAN | Radio | IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v/w/mc/ax; 2x2 MU-MIMO, Wi-Fi 6E (802.11ax), Wi-Fi™ certified; Wi-Fi™ 6 Certified, Dual Band Simultaneous; IPv4, IPv6 |
Data Rates | 6 GHz: 802.11ax—20 MHz, 40 MHz, 80 MHz, 160 MHz—up to 2402 Mbps 5 GHz: 802.11a/n/ac/ax—20 MHz, 40 MHz, 80 MHz, 160 MHz—up to 2402 Mbps; 2.4 GHz: 802.11b/g/n/ax—20 MHz up to 286.8 Mbps | |
Operating Channels | Channel 1-13 (2401-2483 MHz): 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13; Channel 36-165 (5150-5850 MHz): 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140, 144, 149, 153, 157, 161, 165; Channel 1-233 (5925-7125 MHz); Channel Bandwidth: 20/40/80/160 MHz; Actual operating channels/frequencies and bandwidths depend on regulatory rules and certification agency. | |
Fast Roam | PMKID caching; Cisco CCKM; 802.11r; OKC | |
Security and Encryption | WEP (40 or 104 bit); Enhanced Open (OWE); WPA/WPA2 Personal (TKIP, and AES); WPA3 Personal (SAE); WPA/WPA2 Enterprise (TKIP and AES); WPA3 Enterprise (AES) - EAP-TTLS (PAP, MSCHAP, MSCHAPv2), EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC, LEAP, EAP-PWD; WPA3 Enterprise 192-bit mode (GCMP256) - EAP-TLS; TC27 WWAN models only: WPA3 Enterprise EAP-SIM, EAP-AKA, EAP-AKA Prime | |
Certifications | Wi-Fi Alliance Certifications: Wi-Fi CERTIFIED n; Wi-Fi CERTIFIED ac; Wi-Fi CERTIFIED 6; Wi-Fi | |
Fast Roam | PMKID caching; Cisco CCKM; 802.11r; OKC | |
Wireless PAN | Bluetooth | Class 2, Bluetooth v5.2 and Secondary BLE for beaconing within BLE battery |
