The WAI-6510 is the most popular area-imaging scanner engineered to decode all standard 1D, PDF and 2D barcodes. The scanner’s sleek and elegant
design also blends seamlessly in retail environments, providing superior-performance scanning of all printed barcodes, and digital barcodes on any smart device.
Specifications: | ||
|---|---|---|
Physical Characteristics | Dimensions | 100mm*95mm*158mm(L*W*H) |
Weight | 265g | |
Configurations | Decoding | |
Environmental Characteristics | Ambient Light | Fluorescent light 4000 lx max , direct sun light 80,000 lx max ,white light 4000 lx max |
Operating Temperature | 0° to 50°C (operation) | |
Humidity | 5 - 85% (operation) | |
Shock Drop Test | 1.5m drop onto concrete surface | |
| Interface | RS-232/USB HID KEYBOARD/USB VCP |
Voltage Requirement | 5V±10% | |
Current Consumption | Max:200mA | |
Optical Characteristics | Photo Sensor | CMOS array sensor |
Sensor Resolution | 1280X800 pixels | |
Aim Light Source | Red LED | |
Scanning Performance | Min resolution | 1D: 0.076mil/3mil (PCS 0.9) |
Min. PCS value | >30%UPC/EAN 13（13mil） | |
Field of View | 58°(H),45°(V) | |
Supported Barcode Symbologies | Barcode 1D | Codebar，Code128,Code39,Code39,Code93,Code11,EAN13，EAN8，GS1-Databar，GS1-128（EAN-128），Interleaved 2 of 5，Matrix 2 of 5，Industry 2 of 5，UPC-A，UPC-E，ISBN，ISSN |
2D Code | PDF417, Data Matrix, QR Code，Micro PDF417，Micro QR Code，Aztec Code | |
